- It is quite useful in bending both small and big 3D letters that include reverse, trimless letters, and 3D signs.
| Technical Specifications | |||
|---|---|---|---|
| Model | BNZ 3D - 608 | ||
| Structure Size | Outer Size | 1040 mm (L) * 820 mm (W) * 590 mm (H) | |
| Working Size | 600mm * 600mm * 80mm | ||
| Weight | 75 Kg | ||
| Power Supply | Supply Voltage | 110V / 220 V | |
| Power Supply requirement |
50-60Hz, 5.4 - 2.2 A, 450W | ||
| Forming Parameters | Number of Forming Heads |
1 Single Nozzle one | |
| Size of forms Head |
0.6 mm (standard) | 0.8 mm (Select) | |
| Layer Resolution ratio |
100mm | ||
| Posiitonal Accuracy | ≤ 0.03 / 300 mm | ≤ 0.03 / 300 Bending | |
| Torque ≤ 0.03 / 300 mm; Straightness ≤ 0.03 / 300 mm | |||
| Forming Material | PLA, PMMA, PVC | ||
| Material Size | 1.75 mm | ||
| Speed | 100 - 140 mm/s | ||
| Software | Software | 3D Yizhi 1.4.14 | |
| Support system | Windows (7+) | ||
| Type of support Documents |
STL, CDR, ARTCUT | ||
| Human Computer Interface |
Large Screen | 7 inch full color screen - 165 mm(L) * 93 mm(W) | |
